NICHIA NUBM47 Laser Module for Laser Projector | Laser TV | Stage Light Source

NUBM47 Laser Module, 8x Blue diode

NUBM47 is a high-power blue laser module for laser projectors, Laser TV or stage light source.

• Specifications

  Product Name	Nichia Blue Laser Module
  Model	NUBM47
  Output Power	38W （8×4.8W）
  Wavelength	445 nm
  Voltage	29~38V
  Current	< 4.2 A
  Lifespan	> 20,000 hrs
  Operating Temp	0 ~ 70°C
  Storage Temp	−40 ~ 85°C
  Origin	Japan

  Key Features

  • 🔵 8 Collimator beams blue laser diodes (LDs)
  • 🧩 Compact diode array module with mounting bracket, High heat dissipation.
  • 🔌 Easy integration with compatible laser drivers

  Applications

  • Laser projection systems ( Laser projector or Laser TV)
  • Laser engraving and cutting
  • Scientific research and laboratory use
  • Industrial and medical laser equipment
  • Laser lighting and stage effects
  • Large-scale laser landmark installations

  Optional Driver Circuit

  We provide a custom-designed driver for the NUBM47 laser diode. Click here to purchase the compatible driver.

  Shipping & Warranty

  • 🚚 Ships within 24–72 hours
  • 🌍 Global tracked delivery (est. 14 business days)
  • 📦 Shockproof protective packaging
  • 🔄 30-Day worry-free returns.
  • 🛡️ 365-day warranty included
